ABB PPD113B01-10-150000 3BHE023784R0123 UNITROL 6000 X-Power Power Control Board, AC800PEC Excitation High Speed Control Module, Power Generation Excitation Cabinet Spare Part

Description

ABB PPD113B01-10-150000 3BHE023784R0123 UNITROL 6000 X-Power Power Control Board, AC800PEC Excitation High Speed Control Module, Power Generation Excitation Cabinet Spare Part

Product Application

PPD113B01-10-150000 belongs to ABB UNITROL 6000 X-Power series high-speed power control board based on AC800PEC platform. It is the core control unit for generator excitation system, responsible for high-speed sampling of generator voltage/current, AVR regulation calculation, thyristor trigger pulse generation and protection interlock. It cooperates with PPC907BE, PCD235A101 and other boards to build complete excitation control architecture.

• Thermal power plant UNITROL 6000 generator excitation cabinet control
• Hydropower station synchronous generator voltage & reactive power closed-loop regulation
• Combined cycle power unit excitation system dynamic stability control
• Large industrial synchronous motor excitation control
• Power plant excitation system upgrade and spare replacement
• Fast response to grid fluctuation, over-excitation and under-excitation limitation protection
• Nuclear power auxiliary generator excitation control for high reliability requirements

PPD113B01-10-150000

Specifications

• Part Number: PPD113B01-10-150000, 3BHE023784R0123
• Brand: ABB
• Product Type: X-Power High Speed Excitation Power Control Board
• Compatible System: ABB UNITROL 6000, AC800PEC
• Mounting: Eurocard rack mounting inside excitation cabinet
• Dimension: 373 × 142 × 38 mm
• Weight: Approx. 1.0 kg
• Power supply: Auxiliary DC power supplied via backplane
• PCB coating: Conformal coating for anti-corrosion and dust resistance
• Protection Class: IP20, cabinet installation only
• Condition: Original new / refurbished spare available
• Compliance: CE, IEC power control EMC standard, IEC 61000

Parameters

• Control Cycle: Microsecond-level fast control loop
• Regulation Function: Automatic Voltage Regulator (AVR), VAR/PF control, excitation limiters
• Communication: High-speed internal backplane bus, optical sync interface for redundant configuration
• Redundancy: Support dual-module hot standby bumpless switchover
• Operating Temperature: -25°C ~ +70°C
• Storage Temperature: -40°C ~ +85°C
• Relative Humidity: 5%~95% RH, non-condensing
• Shock & Vibration: Comply with IEC 60068 industrial vibration standard
• Status Indicator: On-board LED indicators for power, run, communication and fault status
• Diagnostic: Continuous hardware self-check, channel open/short circuit detection, pulse fault monitoring

Key Features

1. UNITROL6000 X-Power dedicated high-speed control board, realizes high-precision AVR excitation regulation
2. Microsecond-level control cycle, fast response for generator transient disturbance and grid oscillation suppression
3. Optical synchronization interface for redundant dual board architecture, seamless bumpless switchover upon fault
4. Comprehensive built-in excitation limit functions (over-excitation, under-excitation, stator current limit)
5. Conformal coated PCB, anti-dust, anti-humidity and anti-electromagnetic interference for power station environment
6. Standard Eurocard pull-out rack design, convenient on-site maintenance and module replacement
7. Real-time trigger pulse generation for thyristor rectifier bridge, stable excitation output
8. Full factory burn-in and performance testing, critical spare for large generator excitation system

PPD113B01-10-150000

ABB Same Series Related Models (≥6)

1. PPD113B01-10-150000 3BHE023784R0123
2. PPD113B01-25-111000
3. PPD539A102 3BHE039770R0102
4. PPC907BE 3BHE024577R0101
5. PCD235A101 3BHE032025R01
6. PCD231B 3BHE025541R01
7. DATX110 3ASC25H209

Maintenance

• Routine inspection: Check PCB dust accumulation, backplane connector, optical sync cable and LED status every 6–12 months
• Clean board surface with dry compressed air; liquid solvent cleaning is strictly prohibited
• ESD protection must be adopted during disassembly, anti-static wristband required
• If excitation regulation deviation or pulse fault alarm occurs, power off and check backplane contact and optical link
• Do not energize the module if PCB corrosion, burn marks or condensation are found
• We support function testing, refurbishment and spare replacement service for this PPD113B01 excitation control board

Installation

1. Cut off all high voltage and auxiliary power supply of excitation cabinet, confirm zero voltage before operation.
2. Wear anti-static wristband to prevent electrostatic damage to high-speed processor and optical components.
3. Open excitation cabinet door, release the locking mechanism of old PPD113B01 module.
4. Pull out the Eurocard board gently, avoid scratching backplane pins and optical connectors.
5. Insert new -10-150000 board along cabinet guide rail and lock firmly.
6. Reconnect backplane bus and optical synchronization cables, ensure all connectors fully seated.
7. Restore power supply, perform excitation system self-test and inter-board communication verification.
8. Download excitation parameters, carry out no-load excitation test, verify AVR regulation performance and protection interlock before commissioning.
