Name: EATON XV-440-10TVB-1-50 Industrial HMI Touch Panel - MASSIVE
Brand: EATON

Description

XV-440-10TVB-1-50 Industrial HMI Touch Panel Product Specification

Product Title

XV-440-10TVB-1-50 EATON Industrial 10.4-inch TFT Color Touch Screen HMI, High Temperature Resistant Industrial Human-Machine Interface

Product Application

This industrial HMI touch panel is designed for harsh industrial automation environments, delivering stable human-computer interaction, data monitoring, and equipment control functions. It is widely applicable to automated production lines, mechanical manufacturing equipment, packaging machinery, textile machinery, industrial assembly systems, and factory intelligent monitoring systems. The device supports seamless connection with PLC, industrial controllers and upper computer systems, realizing real-time data collection, operation parameter adjustment, fault alarm display and production process visualization management. With excellent environmental adaptability, it can operate stably in high-temperature, dusty and vibration-intensive industrial workshops, meeting the continuous operation demands of industrial automation scenarios.

XV-440-10TVB-1-50

Product Specifications

Display Specifications

Screen Size: 10.4-inch Industrial TFT Color Display
Resolution: 800 × 600 Pixels (SVGA)
Display Colors: 262,144 Colors
Touch Type: Resistive Industrial Touch Screen, support multi-point stable touch operation

Physical & Structural Specifications

Front Protection Grade: IP65 (dust-proof and water splash-proof)
Power Supply: Standard DC 24V Industrial Power Supply
Communication Interfaces: Dual 10/100Mbps Ethernet (PoE supported), USB 2.0 Host ×2, USB 2.0 Device ×1, RS485 (Modbus RTU protocol supported)
Working Temperature Range: 0℃ ~ +50℃
Storage Temperature Range: -20℃ ~ +70℃
Anti-vibration Grade: Industrial grade anti-vibration, adapt to equipment operation vibration environment

Product Features

Industrial Grade Stability & Durability: Adopts high-strength industrial shell and exclusive anti-interference design, effectively resist industrial electromagnetic interference, dust, water splash and mechanical vibration. The wide temperature working range ensures long-term stable operation in complex and harsh industrial scenarios without crash or screen flicker.
Powerful Communication & Compatibility: Rich built-in industrial communication interfaces, compatible with mainstream industrial protocols such as Modbus RTU. It supports seamless docking with various brands of PLC, servo systems and industrial control equipment, realizing efficient data transmission and signal interaction.
Flexible Programmable Configuration: Equipped with graphical visual programming software, no complex professional programming technology required. Users can independently customize operation interfaces, control logic, parameter monitoring windows and fault alarm prompts to meet personalized control demands of different production equipment.
Efficient Data Processing & Storage: Equipped with independent large-capacity memory, which can stably store production data, operation logs and parameter settings. It supports real-time data refresh and historical data query, facilitating production data statistics and equipment operation analysis.
User-Friendly Operation: High-definition color display with clear screen display and sensitive resistive touch response, supporting stable operation even with gloves. The humanized interface design simplifies industrial operation steps and improves on-site operation efficiency.
Easy Installation & Maintenance: Standard embedded panel structure, compact and integrated design, saving installation space. Modular internal structure simplifies daily inspection and fault maintenance, reducing equipment downtime and maintenance cost.

XV-440-10TVB-1-50

Installation Instructions

Install the device in a dry, ventilated and non-corrosive industrial control cabinet or equipment panel, avoid direct sunlight and long-term high-temperature radiation.
Adopt standard embedded mounting, fix the equipment with matching mounting brackets to ensure firm installation and avoid loose caused by equipment vibration.
Strictly follow industrial wiring specifications for power supply and signal wiring, ensure DC 24V stable power input, and do a good job of line anti-interference shielding treatment.
Complete interface connection and wiring inspection before power-on test, confirm no short circuit or wrong connection, then perform system debugging and parameter configuration.
Reserve heat dissipation space around the equipment to avoid heat accumulation affecting service life and operation stability.

Maintenance Guidelines

Daily Maintenance: Regularly clean the screen surface with soft dry cloth to remove dust and stains; check whether the power line and communication line are loose or aging, and ensure good contact of interfaces.
Regular Inspection: Quarterly check the equipment operation temperature, touch sensitivity and data transmission stability; regularly back up system parameters and operation data to prevent data loss.
Fault Maintenance: In case of screen failure, data delay or unresponsive touch, first cut off the power supply for restart inspection; do not disassemble the equipment privately. For complex faults, contact professional technical personnel for maintenance.
Environmental Maintenance: Keep the installation environment dry and clean, avoid humid, dusty and corrosive gas environment; regularly check the heat dissipation effect to prevent equipment overheating failure.
Service Life Maintenance: Avoid frequent power on and off and violent touch operation; regularly update system configuration and optimize program logic to maintain long-term stable operation of the equipment.

Brand Same-Series 6 Models

All models belong to EATON XV-440 industrial HMI series, with consistent industrial grade performance and compatible communication protocols, covering different specifications and temperature resistance grades for diverse industrial demands:
