C400/10/1/1/1/00 Industrial HMI Operator Panel Product Specification



Product Title

C400/10/1/1/1/00 10-inch Industrial TFT Touch Screen HMI, Beijer Electronics Compact Industrial Human-Machine Interface for Factory Automation Control



Product Application

The C400 series industrial HMI is engineered for general and harsh industrial automation environments, serving as a core human-machine interaction terminal for on-site equipment monitoring, parameter configuration, operational control and data visualization. It is widely deployed in automated production lines, packaging machinery, material handling equipment, textile and printing machinery, food and beverage processing equipment, HVAC industrial control systems, and smart factory auxiliary control units. Featuring excellent anti-interference capability and wide-temperature adaptability, this HMI supports stable long-cycle operation in dusty, vibrating and temperature-fluctuating industrial workshops. It achieves seamless data linkage with PLCs, servo controllers and industrial I/O modules, enabling real-time data acquisition, equipment fault alarming, production process tracking and remote local operation management.

C400/10/1/1/1/00

Product Specifications

Display & Touch Specifications

  • Screen Size: 10-inch Industrial TFT LED Backlight Display
  • Native Resolution: 1024 × 600 / 800 × 600 Industrial Standard Resolution
  • Display Mode: High contrast industrial-grade color display, wide viewing angle
  • Touch Technology: Industrial resistive touch screen, glove-touch compatible, anti-scratch and durable
  • Backlight Lifespan: 50,000+ hours long service life

Structural & Environmental Specifications

  • Front Panel Protection: IP65 rated (dust-tight and splash-proof)
  • Rear Housing Protection: IP20 rated
  • Installation Type: Standard embedded panel mounting
  • Certification Compliance: CE, FCC, industrial EMC certification



Core Technical Parameters

  • Main Processor: Industrial high-stability dedicated CPU, low power consumption
  • System Memory: Onboard industrial DDR memory + high-speed flash storage
  • Operating System: Embedded real-time industrial operating system
  • Power Supply: Standard industrial DC 24V power supply (18–30V wide voltage range)
  • Communication Interfaces: Ethernet port (Modbus TCP/IP), RS485/RS232 serial port (Modbus RTU), USB 2.0 interface
  • Operating Temperature: -20℃ to +60℃ industrial wide temperature range
  • Storage Temperature: -30℃ to +70℃
  • Vibration Resistance: Compliant with IEC 60068-2-6 standard (4g industrial anti-vibration grade)
  • Shock Resistance: Compliant with IEC 60068-2-27 standard (15G anti-shock performance)
  • EMC Performance: Meet EN 61000-6-4 industrial emission standard and EN 61000-6-2 industrial immunity standard
  • Data Storage: Support local log recording, parameter storage and historical data retention



Recommended Matching Models (8 Models)

The following controllers and peripheral modules are perfectly matched with C400/10/1/1/1/00 HMI for integrated automation control solutions:

  • FX5U-32MT Industrial PLC Controller
  • S7-1214C Siemens Compact PLC Module
  • CP1E-E40 Omron Programmable Controller
  • DVP-EC3 Delta Industrial PLC
  • GT-3911 Analog Input Module
  • GT-4258 Digital Output Module
  • GL-9073 Industrial Communication Adapter
  • GN-9284 Fieldbus Expansion Module

C400/10/1/1/1/00

Product Features

  • Industrial-Grade Extreme Stability: Adopts low-power industrial hardware architecture and full EMC anti-interference design, which effectively resists industrial electromagnetic interference, mechanical vibration and temperature changes. The wide-temperature operating range ensures 7×24-hour continuous stable operation without screen crash, flash or data loss in complex factory environments.
  • Powerful Protocol Compatibility: Built-in mainstream industrial communication protocols including Modbus RTU, Modbus TCP/IP, supporting automatic docking with multi-brand PLCs, servo systems and fieldbus equipment. It features fast data response and high transmission accuracy, realizing efficient interactive control of automation systems.
  • User-Friendly Visual Configuration: Matches professional graphical configuration software, supporting drag-and-drop programming, customized operation screens, dynamic data display, trend curve recording and multi-level password authority management. The intuitive operation logic greatly reduces programming difficulty and improves project deployment efficiency.
  • Durable Industrial Touch Screen: Adopts high-hardness resistive touch panel with scratch resistance and solvent corrosion resistance, supporting stable operation with gloves. The long-life LED backlight ensures clear display in strong light and dim light environments, adapting to all-day industrial operation scenarios.
  • Compact & Integrated Design: Integrated display, touch and control unit with compact structure, saving installation space of control cabinets. The embedded installation structure is firm and reliable, not easy to loose under long-term vibration conditions.
  • Complete Data Management Function: Supports real-time data monitoring, historical data recording, fault alarm logging and data export. It can store massive production and operation data, providing reliable data support for production analysis, equipment maintenance and production optimization.
  • Low Maintenance & High Adaptability: Modular internal structure simplifies daily inspection and fault troubleshooting. The wide-voltage power supply design adapts to unstable industrial power supply, avoiding equipment shutdown caused by voltage fluctuation.



Installation Guidelines

  • Install the HMI in a dry, ventilated and non-corrosive industrial control cabinet, avoiding direct sunlight, high-temperature heat source radiation and heavy dust accumulation areas.
  • Adopt standard embedded panel mounting, use matched fixing brackets to lock the equipment tightly to prevent displacement caused by equipment vibration during operation.
  • Follow industrial wiring specifications for power and signal wiring. Access stable DC 24V industrial power supply, and separate power lines and signal lines to avoid signal interference.
  • Complete all interface wiring and conduct circuit inspection before power-on, confirm no short circuit or wrong connection, then perform power-on test, system configuration and program download.
  • Reserve sufficient heat dissipation space around the equipment to avoid heat accumulation, ensuring long-term stable operation of internal hardware.
  • The equipment supports vertical and horizontal installation, which can be flexibly arranged according to on-site cabinet layout requirements.



Maintenance Instructions

  • Daily Routine Maintenance: Regularly wipe the screen surface with a soft dry lint-free cloth to remove dust and stains; check whether power lines and communication lines are loose, aging or damaged, and ensure reliable interface connection.
  • Periodic Inspection Maintenance: Conduct quarterly inspection of equipment operating temperature, touch sensitivity, display clarity and data transmission stability. Regularly back up system programs and parameter data to prevent accidental data loss.
  • Fault Handling Maintenance: In case of screen abnormality, unresponsive touch or data delay, cut off the power supply and restart the equipment for self-inspection first. Do not disassemble the equipment privately to avoid damaging internal precision components. Contact professional technical personnel for overhaul for complex faults.
  • Environmental Maintenance: Keep the installation environment clean and dry, avoid humid, corrosive gas and heavy dust environments. Regularly check the heat dissipation condition to prevent equipment failure caused by overheating.
  • Long-Term Operation Maintenance: Avoid frequent power on/off and violent touch operation. Regularly optimize system programs and clean background logs to maintain efficient and stable operation of the equipment.



Brand Same-Series Models (6 Models)

All models belong to Beijer C400 industrial HMI series, with consistent industrial-grade performance, protocol compatibility and installation specifications, covering multi-size and multi-configuration options:

    • C400/07/1/1/1/00 (7-inch Basic Version)
    • C400/10/2/1/1/00 (10-inch Dual Ethernet Version)
    • C400/10/1/2/1/00 (10-inch Enhanced Communication Version)
    • C400/12/1/1/1/00 (12-inch Standard Version)
    • C400/15/1/1/1/00 (15-inch Large Screen Version)
    • C400/10/1/1/2/00 (10-inch High-Temperature Resistant Version)
