ICS TRIPLEX T8842 Versatile Field Termination Assembly(VFTA)
Product Overview
T8842 is the versatile multi‑function field termination assembly (VFTA/FTA) for Rockwell ICS TRIPLEX Trusted TMR SIS safety‑instrumented system. It is DIN‑rail mounted field‑side termination hardware, working with zone interface module T8448 / T8449, supports software‑configurable 40 channels for AI 4‑20 mA, DI 24 VDC, fire‑gas loop inputs and monitored valve outputs. The 40 channels are divided into 5 independent power groups (8 channels per group), each group with plug‑in fuses for loop‑level fault containment. It provides surge suppression, loop power supply, field wiring termination and circuit diagnostics for F&G fire‑gas and ESD safety loops. Legacy hardware, OEM production discontinued, mainly supplied as spare‑parts for oil‑gas, petrochemical and power‑plant SIS installations.
Typical Applications
- Oil‑gas & petrochemical F&G system: Field termination for fire detectors, gas sensors, smoke detectors, flame sensors
- ESD emergency shutdown system: Interface for safety transmitters, interlock switches, solenoid valve monitored outputs
- Chemical plant safety interlock: Mixed analog‑digital signal field termination for large‑scale SIS projects
- Off‑shore platform safety cabinet: Suitable for marine and offshore hazardous‑area cabinet layout
- Power‑plant safety system: Fire‑gas detection and safety‑loop field wiring interface for boiler‑turbine SIS
- Brown‑field retrofit & spare‑part replacement: Renewal of VFTA termination hardware for existing Trusted installations
ICS T8842
Specifications & Technical Parameters
| Item | Specification |
|---|---|
| Model | T8842 Versatile FTA(VFTA) |
| System Compatibility | Trusted SIS; pairs with T8448 / T8449 zone interface module |
| Channel Count | 40 configurable channels, divided into 5 independent power groups (8 ch/group) |
| Configurable Signal Types | 4‑20 mA analog input; 24 VDC digital input; fire‑gas loop input; monitored valve outputRockwell A… |
| Power Supply | 18‑28 VDC field supply; max 2.52 A per power group; max total power consumption 9 WMoore Auto… |
| Per‑channel Current | Max 220 mA per channelMoore Auto… |
| Installation | Standard 35 mm DIN‑rail mounting |
| Fuse | Field‑replaceable plug‑in fuses per power group |
| Galvanic Isolation | Field‑to‑backplane isolation |
| Operating Temperature | ‑5 ℃ ~ +60 ℃ |
| Storage Temperature | ‑25 ℃ ~ +70 ℃Moore Auto… |
| Humidity | 10‑95 % RH, non‑condensingMoore Auto… |
| Dimension(H×W×D) | 110 × 360 × 68 mm |
| Weight | Approx. 0.95 kg |
| Certifications | CE, UL compliant |
| Protection Class | IP20 (cabinet‑mount only) |
Key Features & Benefits
- Multi‑function configurable channels: Single hardware supports analog input, digital input, fire‑gas detector loop and monitored valve output, reduces spare‑part types for mixed‑signal safety‑system cabinetsRockwell A….
- Five independent power‑group design: 40 channels split into 5 groups of 8 channels, each group protected by independent plug‑in fuse; fault in one group will not affect other groups, implements group‑level fault containment.
- Dedicated for F&G safety loops: Optimized for fire‑gas detector field wiring, provides loop power supply and circuit fault diagnostics for fire/gas safety detection.
- DIN‑rail compact mechanical structure: Easy cabinet layout, plug‑in fuse design simplifies on‑site maintenance.
- Comprehensive field‑loop diagnostics: Reports short‑circuit, open‑circuit and fuse‑fault status back to T8448 zone interface module for SIS system alarm processing.
- Seamless Trusted ecosystem matching: Works cooperatively with T8448/T8449 zone interface module, connects to Trusted TMR processor and I/O packs.
Related Series‑Family Models (Trusted FTA/VFTA family)
ICS TRIPLEX Trusted field termination hardware
- T8842: 40‑channel multi‑function versatile FTA (target model)
- T8843: 40‑ch digital‑input dedicated VFTA
- T8844: 40‑ch analog‑input dedicated VFTA
- T8847: 40‑ch fire‑input dedicated VFTA
- T8448 / T8449: Zone interface module for T8842 VFTA
- T8403: 40‑ch TMR digital input module
- T8431: 40‑ch TMR analog input module
