Bently Nevada 3300/15 Power Supply Module
Part Number: 330500-01-00
1. Product Introduction
The 330500-01-00 is a high-efficiency, linear power supply module engineered for the Bently Nevada 3300 Series Monitoring System. It serves as the primary power source for the rack, converting standard AC line voltage into the stable, low-voltage DC power required to operate monitoring modules, relays, and communication interfaces. This specific model is designed with redundant capabilities, allowing two units to operate in parallel (one active, one standby) to ensure uninterrupted power delivery to critical machinery protection systems.
330500-01-00
2. Main Technical Specifications
- Part Number Breakdown:
- 330500: 3300 Series Power Supply.
- 01: Input Voltage Option. This unit accepts 175 to 264 VAC (50/60 Hz, Single Phase). *Note: This is the High Voltage version; it is not compatible with Low Voltage (85-132 VAC) sources without a transformer.*
- 00: Standard options / approvals.
- Input Power:
- Voltage Range: 175 to 264 VAC RMS.
- Frequency: 50 or 60 Hz.
- Current: Typically < 1.5 A.
- Output Power:
- +5 VDC: Main logic power for monitors (typically up to 8A or 12A depending on rack loading).
- +24 VDC: Power for relays, transducers, and external accessories (typically up to 2A).
- -24 VDC: Power for Proximity Transducers (Proximitors).
- Floating vs. Grounded: Outputs are typically isolated from the chassis ground (floating) to facilitate proper system grounding.
- Physical Dimensions:
- Standard Module Size: Fits into a 3300 Series Rack (Full-height or half-height depending on specific rack chassis).
- Environmental:
- Operating Temperature: 0°C to +65°C (32°F to +149°F).
- Storage Temperature: -40°C to +85°C (-40°F to +185°F).
3. Typical Applications
The 330500-01-00 is utilized across various industries to power continuous monitoring systems:
- Turbine-Generator Sets: Providing stable power to radial vibration, axial position, and eccentricity monitors.
- Refinery & Petrochemical Plants: Powering pumps and compressors monitoring racks in hazardous areas.
- Redundant Power Architectures: Used in critical API 670 compliant setups where power failure is not an option (N+1 redundancy).
- Retrofit Projects: Replacing legacy power supplies in existing 3300 racks to extend system life.
4. Avoid Technical Pitfalls (Best Practices & Warnings)
- Voltage Rating Mismatch (Critical): The “-01” suffix indicates High Voltage (175-264 VAC). Applying 110/120 VAC to this unit will result in under-voltage and the power supply will not function. Conversely, applying 240 VAC to a “-02” (Low Voltage) unit will destroy it immediately.
- Supply vs. Demand: Ensure the total current draw of all modules in the rack does not exceed the power supply’s rated capacity. Overloading the +5V bus can cause intermittent resets or complete system failure.
- Hot Swap Limitations: Unlike the newer 3500 Series, the 3300 Series racks may not support true “Hot Swapping” (insertion/removal while powered) without tripping breakers or causing voltage spikes. Always power down the rack before replacing this module.
- Grounding and Bonding: This module provides isolation between input and output. The rack ground must be connected to the plant earth ground separately. Do not rely on the AC ground pin to serve as the signal ground, as this introduces noise.
- Fan Failure: Ensure the rack cooling fans are operational. This power supply generates significant heat; insufficient cooling will lead to thermal shutdown and reduced lifespan.
