ABB PM864AK02 3BSE018164R1 Redundant Processor Unit Kit, AC800M 800xA DCS High Availability CPU Controller Module, Industrial Process Automation Spare Part



Product Application

PM864AK02 is a redundant CPU kit for ABB AC800M / 800xA distributed control system. It contains dual PM864A processor units and baseplates, supporting hot standby redundant architecture. It executes real-time control logic, PID calculation, data acquisition and communication management for continuous process industries.

  • Power plant boiler and turbine control system
  • Petrochemical continuous process monitoring and closed-loop control
  • Oil & gas compressor station and pipeline process control
  • Metallurgy rolling mill and furnace automation
  • Cement plant kiln and material handling line control
  • Water & wastewater treatment large-scale distributed control
  • Upgrade and spare replacement for legacy ABB AC800M redundant DCS systems

PM864AK01 3BSE018161R1

Specifications

  • Part Number: PM864AK02, 3BSE018164R1
  • Brand: ABB
  • Product Type: Redundant Processor Unit Kit
  • Compatible System: ABB AC800M, 800xA System
  • Mounting: Rack slot mounting on CEX bus backplate (TP830 baseplate included)
  • Protection Class: IP20 (cabinet installation only)
  • Dimension: 119 × 186 × 135 mm
  • Weight: Approx. 1.2 kg (full kit)
  • Power supply: 24VDC via backplane
  • Power consumption: Max 15W for the kit
  • Processor: 96MHz industrial processor
  • Memory: 32MB RAM
  • Included accessories: Dual PM864A CPU, dual TP830 baseplates, redundancy sync cable
  • Condition: Original new / refurbished spare available
  • Compliance: CE, IEC EMC standard, ISA 71.04 G3 anti-corrosion coating



Parameters

  • Redundancy Mode: 1+1 hot standby, bumpless switchover ≤10ms
  • Communication: Dual onboard Ethernet ports (RNRP redundancy protocol), CEX bus for expansion modules, ModuleBus for S800 I/O
  • Max CEX modules: Up to 12 modules per controller
  • Hot Swap: Supported
  • Programming Standard: IEC 61131-3
  • Operating Temperature: 0°C ~ +55°C
  • Storage Temperature: -40°C ~ +70°C
  • Relative Humidity: 5%~95% RH, non-condensing
  • Status Indicator: Front panel LED indicators for power, run, fault, link and redundancy status
  • Function: Real-time control, program execution, data logging, redundancy synchronization



Key Features

  1. Complete redundant CPU kit for AC800M, fast bumpless switchover when primary CPU fails
  2. 96MHz processor with 32MB RAM, suitable for complex continuous process control applications
  3. Dual Ethernet ports with RNRP protocol for network redundancy
  4. CEX bus expansion to connect multiple communication and I/O modules
  5. Hot-swap capable, single CPU replacement without system shutdown
  6. G3 conformal coating, stable operation in dusty and corrosive industrial environments
  7. Front LED diagnostic indicators for fast redundancy status and fault troubleshooting
  8. IEC 61131-3 programming support, compatible with Compact Control Builder engineering software

PM864AK01 3BSE018161R1

ABB Same Series Related Models (≥6)

  1. PM864AK02 3BSE018164R1
  2. PM864AK01 3BSE018161R2
  3. PM861AK02 3BSE018129R1
  4. PM866K01 3BSE018158R1
  5. PM856 3BSE018105R1
  6. PM860 3BSE018100R1
  7. PM865K01 3BSE031151R1



Maintenance

  • Routine inspection: Check module LED status, backplane connector and redundancy sync cable condition every 6–12 months
  • Clean module surface with dry compressed air; liquid solvent cleaning is strictly prohibited
  • ESD protection must be adopted during disassembly, anti-static wristband required
  • If redundancy switchover alarm triggers, check sync cable, Ethernet connection and CPU health status
  • Do not energize the module if PCB corrosion, burn marks or condensation are found
  • We support function testing, refurbishment and spare replacement service for this redundant processor kit



Installation

  1. Follow DCS safety operation procedure; hot-swap replacement can be executed under safe operating condition or cut off cabinet power supply.
  2. Wear anti-static wristband to prevent electrostatic damage to PCB components.
  3. Install TP830 baseplates on rack slots, insert two PM864A processor modules and lock fastening latches.
  4. Connect redundancy synchronization cable between the two CPUs.
  5. Connect shielded Ethernet cables to onboard RJ45 ports for control network.
  6. Configure controller parameters, redundancy settings and download control program via engineering software.
  7. Restore power supply, verify CPU synchronization and redundant switchover status.
  8. Perform loop test and commissioning; validate bumpless failover function between primary and standby CPU.
