Name: TRICONEX 3625A TMR Digital Output Module - MASSIVE
Brand: Triconex

Description

TRICONEX 3625A TMR Digital Output Module Product Introduction

The TRICONEX 3625A is a high-density, fault-tolerant TMR (Triple Modular Redundancy) digital output module designed for Triconex Safety Instrumented Systems (SIS). As a core 32-channel discrete output unit for industrial safety control, it delivers reliable switching signal output, precise actuator driving and full-loop status diagnosis for critical safety loops. Built with exclusive triple redundant hardware architecture and industrial-grade anti-interference design, the 3625A fully complies with IEC 61508 SIL 3 functional safety standards, ensuring fail-safe and uninterrupted safety interlock execution in high-risk process industrial environments.

Product Applications

The TRICONEX 3625A is widely deployed in safety-critical industrial scenarios requiring high-density digital safety output and high-availability loop control, covering oil & gas, petrochemical, chemical processing, thermal power generation, energy and pharmaceutical industries. It serves as a key execution module for SIS, ESD and F&G safety systems, with typical application scenarios as follows:

Emergency Shutdown (ESD) System Execution: Drives 24VDC safety solenoid valves, trip relays and emergency shutdown actuators, executing fast isolation and equipment shutdown commands when process parameters exceed safety thresholds to prevent hazardous accidents.
Fire & Gas (F&G) Linkage Control: Outputs discrete control signals for fire alarm beacons, gas isolation valves, exhaust fans and fire suppression equipment, realizing rapid hazard response and graded safety linkage protection.
Massive Safety Interlock Loop Control: Adapts to large-scale industrial safety systems with numerous interlock points, realizing centralized high-density digital output management and simplifying system I/O configuration and wiring layout.
Process Equipment Safety Protection: Controls auxiliary safety equipment such as process pumps, safety baffles and pressure relief auxiliary devices, ensuring stable and orderly execution of process safety protection logic.
DCS & SIS Cooperative Output Control: Cooperates with SIS input modules and communication modules to realize coordinated safety output between safety systems and conventional process control systems, improving overall production safety integrity.

TRICONEX 3625A

Technical Specifications & Parameters

The TRICONEX 3625A adopts industrial-grade high-density digital output design, with standardized electrical, environmental and mechanical parameters. It features stable load driving capability and strict safety specifications, fully meeting SIL 3 high-reliability safety loop control requirements. Detailed specifications are listed below:

2.1 Electrical & Output Parameters

Module Type: TMR triple redundant digital output module
Channel Configuration: 32 independent high-density digital output channels
Nominal Output Voltage: 24VDC industrial safety voltage
Operating Voltage Range: 16VDC to 32VDC continuous working range
Maximum Withstand Voltage: 36VDC transient tolerance
Single Channel Load Capacity: Standard industrial load driving current
Output Mode: Isolated discrete switching output, common terminal design
Response Characteristic: Fast switching response to meet real-time safety interlock action requirements
Isolation Design: Complete galvanic isolation between field side and system backplane, avoiding signal crosstalk and interference

2.2 Environmental Parameters

Operating Temperature: -40°C to +70°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing)
Environmental Resistance: Compliant with IEC industrial vibration, shock and EMC electromagnetic interference resistance standards
Working Adaptability: Supports long-term continuous unattended operation in harsh industrial environments

2.3 Mechanical & Certification Parameters

Installation Method: Standard Triconex TMR chassis slot mounting
Hot-Swap Support: Allows online module replacement without system shutdown
System Compatibility: Fully compatible with all Triconex TMR controllers, chassis and TriStation software
Safety Certification: IEC 61508 SIL 3 certified, TÜV, CE, UL, ATEX compliant
Design Service Life: More than 10 years under standard industrial operating conditions

Core Product Features

3.1 TMR Triple Modular Redundancy Fault-Tolerant Architecture

The TRICONEX 3625A inherits Triconex exclusive three-channel synchronous redundant design, equipped with hardware two-out-of-three voting logic. Three independent internal output processing channels synchronously execute control commands and status verification. Single-channel hardware failure, signal deviation or transient abnormality will be automatically identified and isolated. The module maintains normal output status through healthy channel consensus, completely eliminating single-point failure risks and ensuring zero interruption of safety interlock loops.

3.2 High-Density Channel Integration & Cost Efficiency

Featuring 32 high-integrated output channels, the 3625A greatly improves the I/O density of SIS systems, effectively saving cabinet space and reducing wiring and module deployment costs. The unified common terminal design simplifies on-site wiring layout, reduces construction errors and hidden wiring troubles, and is especially suitable for large-scale safety control scenarios with dense output points.

3.3 Full-Coverage Intelligent Self-Diagnosis

The module integrates comprehensive real-time diagnosis functions, which can accurately detect channel output abnormality, field loop open circuit/short circuit, load failure, power supply fluctuation and internal circuit faults. All fault codes and channel status information are uploaded to the upper monitoring system in real time, supporting precise fault location, proactive early warning and rapid troubleshooting, and significantly improving system operation maintainability.

3.4 Strict Fail-Safe Protection Mechanism

Following industrial safety fail-safe design principles, the 3625A will automatically switch to a predefined safe de-energized state in case of module failure, voting mismatch, communication interruption or power abnormality. It locks safety output status and triggers alarm signals, effectively preventing system misoperation and ensuring maximum safety integrity of industrial production and equipment operation.

3.5 Excellent Harsh Environment Adaptability

Adopting industrial-grade reinforced hardware and wide-temperature design, the module can operate stably in extreme environments such as low temperature, high temperature, high humidity, strong vibration and complex electromagnetic interference. With outstanding anti-aging, dust-proof and anti-corrosion performance, it fully adapts to long-term continuous operation requirements of field process industries.

3.6 Convenient Maintenance & Strong System Scalability

Supports online hot-swap replacement and maintenance without shutting down the SIS system, effectively reducing production downtime and operation risks. Fully compatible with the complete Triconex TMR system ecosystem, it supports flexible system I/O expansion and logic upgrade, meeting the iterative upgrade and capacity expansion needs of large-scale industrial automation systems in the later stage.

TRICONEX 3625A

Similar Series Models

The Triconex 3600 series covers full-range high-reliability digital output modules for TMR safety systems, adapting to different channel density and voltage level control scenarios. The mainstream similar and matching models of the TRICONEX 3625A are listed below for system configuration, replacement and expansion reference:

TRICONEX 3625: Standard version of 3625A high-density digital output module, suitable for conventional 24VDC safety loop control scenarios.
TRICONEX 3623T: 16-channel 120VDC supervised digital output module, applicable to high-voltage high-power actuator control scenarios.
TRICONEX 3411: Classic solid-state digital output module, cost-effective for general low-density safety output loops.
TRICONEX 3301: 32-channel digital input module, cooperating with 3625A to complete full-loop signal acquisition and linkage output control.
TRICONEX 3704E: High-precision analog input module, providing process parameter data for 3625A safety interlock judgment.
TRICONEX 5101S2: Safety communication module, realizing real-time upload of 3625A output status and fault diagnosis data.

Product Summary

The TRICONEX 3625A is a high-density SIL 3-grade TMR digital output module in the Triconex safety system product line. With triple modular redundant fault-tolerant architecture, 32-channel high-integrated output capability, intelligent full-loop diagnosis and strict fail-safe protection mechanism, it solves the problems of insufficient I/O density and high deployment cost of traditional safety output modules. As a core high-efficiency execution unit for SIS, ESD and F&G systems, it provides stable, accurate and reliable digital output guarantee for large-scale industrial safety loops, and is widely applied in global high-risk process industries.
