H90QHQE013N0 Foxboro H90 Rackmount Industrial Server, I/A Series DCS Operator Workstation & Application Node



Product Application

H90QHQE013N0 belongs to Foxboro H90 workstation family under Schneider Electric I/A Series DCS ecosystem. It is a dedicated industrial server node for distributed control system. Typical deployment: operator HMI station, engineering workstation, application server for control core service, historian data collection node, alarm & event management host. Widely used in petrochemical, refining, power plant and chemical process plant. Runs Foxboro certified I/A Series operation software, communicates with I/A controllers and field I/O modules via DCS control network. Redundant architecture design ensures continuous operation for critical process control.

H90 H90C9AA0117S

Product Specifications

  • Part Number: H90QHQE013N0
  • Manufacturer: Foxboro (Schneider Electric)
  • Product Type: 2U 19-inch Rackmount Industrial Workstation Server
  • Processor: Intel Xeon E5‑2609v3 multi‑core CPU
  • Memory: ECC enterprise RAM (configurable)
  • Storage: Hot‑swap SAS/SATA hard drives, hardware RAID 1 mirroring
  • Network: 4 × Gigabit Ethernet ports for DCS control LAN
  • Front I/O: Dual USB3.0 ports
  • Power Supply: Dual hot‑swap redundant 750W AC power, 100‑240VAC, 50/60Hz auto‑switching
  • Cooling: Dual redundant hot‑swap fans, front‑to‑rear airflow
  • Certified OS: Windows Server 2008 R2 / 2012 R2 / 2016 (Foxboro pre‑validated image for I/A Series)
  • Operating Ambient Temp: 5 ℃ ~ +40 ℃ inlet air
  • Mechanical: Standard 2U EIA‑310‑D rack chassis
  • Gross Weight: 18 ~ 22 kg, varies with HDD & memory configuration
  • Product Status: Spare replacement workstation for existing I/A Series DCS projects



Core Technical Parameters

  • Architecture: Industrial server grade platform, long‑term stable operation for DCS without frequent reboot
  • Redundancy: Redundant PSU + redundant fan + RAID1 storage to eliminate single point of failure
  • Network isolation: Four Gigabit LAN ports support separate control network, historian network and office network isolation
  • DCS software compatibility: Fully compatible with I/A Series control software suite, Foxboro engineering & operator station application
  • Maintenance design: Hot‑swap power, fan and hard disk, replaceable without powering down whole workstation
  • Safety: Industrial EMC compliance for control room environment



Recommended Matching Spare Parts & Accessories (8 Items)

  1. Hot‑swap SAS hard disk for RAID group
  2. Replacement 750W redundant power supply module
  3. Hot‑swap fan assembly
  4. Foxboro I/A Series workstation software license
  5. Shielded DCS control network Ethernet cable
  6. Industrial KVM switch for rack workstation remote operation
  7. Rack mounting slide rail kit
  8. Workstation UPS uninterruptible power supply

H90 H90C9AA0117S

Product Features

✅ Foxboro I/A Series DCS Dedicated Workstation Factory validated hardware platform, stable compatibility with I/A control software, no driver conflict risk in DCS environment.

✅ Full Redundancy Design Dual hot‑swap power supplies, redundant cooling fans and RAID1 mirrored storage. Fault of single component will not shut down workstation service.

✅ Multi‑Port Gigabit Ethernet Four independent Gigabit network adapters, easy to separate control domain, historian and office network to meet DCS network partition security requirements.

✅ 2U Compact Rack Mount Chassis Standard 19-inch 2U rack installation, saves control cabinet space.

✅ Hot‑Swap Maintainable Components Hard disk, power supply and fan can be replaced on site without workstation shutdown, shortens maintenance downtime.

✅ Enterprise Xeon CPU + ECC Memory High‑performance multi‑core processor with error‑correction memory, stable for long‑time HMI graphic rendering, alarm calculation and data historian tasks.

✅ Foxboro Certified Windows Server OS Pre‑tested operating system image, optimized for I/A DCS service, avoids ordinary commercial PC compatibility problems.



Installation Guidelines

  1. Install the 2U workstation into standard 19‑inch control cabinet with slide rail kit, reserve ventilation space at front and rear for airflow.
  2. Connect dual power cords to two independent UPS power circuits to realize power source redundancy.
  3. Assign Ethernet ports to different DCS subnets, connect to I/A control network switch with shielded network cable.
  4. Configure hardware RAID 1 for two hard disks in BIOS level.
  5. Deploy Foxboro I/A workstation operating system and software license.
  6. Assign station node address in I/A control network, download controller graphic and alarm configuration.
  7. Test redundant power failure: cut off one AC power feed to verify workstation keeps running normally.
  8. Verify RAID disk fault tolerance: simulate single hard disk offline to confirm system continues operation.



Maintenance Instructions

Daily Maintenance Check workstation running status on DCS HMI. Monitor RAID disk health alarm. Check PSU indicator light and cabinet cooling air flow.

Periodic Maintenance (Every 6–12 months) Clean dust on air inlet filter. Check Ethernet cable connection status. View system event log and RAID log. Backup I/A workstation configuration and operating system image.

Fault Maintenance

  • RAID disk failure: Replace faulty hot‑swap hard disk, wait RAID reconstruction complete.
  • Single power supply alarm: Swap defective power module without shutting down workstation.
  • Workstation crash or service exception: Check OS event log, verify network communication with I/A controllers.
  • Do not modify BIOS and RAID parameters arbitrarily without DCS engineer authorization.

Long‑Term Operation Tips Maintain control room temperature within 5~40℃. Keep stable UPS power supply. Backup workstation system image for quick disaster recovery. Stock spare hot‑swap power and hard disk.
