ABB XVC767AE102 3BHB007209R0102 High Precision Analog Input/Output Module, S800 I/O Advant OCS Signal Conditioning Module, Industrial Process Control Spare Part



Product Application

XVC767AE102 is a multi-channel analog I/O module for ABB S800 I/O and Advant OCS control system. It performs analog signal acquisition, conditioning and output transmission between field transmitters, actuators and the main controller.

  • Power plant boiler and turbine analog signal monitoring
  • Petrochemical plant flow, pressure, temperature continuous measurement and control
  • Oil & gas refinery process closed-loop regulation
  • Metallurgy furnace and rolling mill analog parameter collection
  • Water & wastewater treatment dosing and level control
  • Pharmaceutical and chemical batch process automation
  • Legacy ABB Advant OCS / S800 I/O system spare replacement and retrofit

XVC767AE102 3BHB007209R0101

Specifications

  • Part Number: XVC767AE102, 3BHB007209R0102
  • Brand: ABB
  • Product Type: Analog Input / Output Module
  • Compatible System: ABB S800 I/O, Advant OCS
  • Mounting: Rack slot mounting on S800 baseplate
  • Protection Class: IP20 (cabinet installation only)
  • Weight: Approx. 0.32 kg
  • Power supply: 24VDC supplied via S800 baseplate
  • Channel: 8 configurable analog channels
  • Condition: Original new / refurbished spare available
  • Compliance: CE, IEC EMC standard, ISA 71.04 G3 coating



Parameters

  • Signal Type: Voltage (0~10V, ±10V), Current (4~20mA, 0~20mA)
  • Resolution: 16-bit, measurement accuracy 0.0015%
  • Sampling Rate: Up to 100 samples per channel per second
  • Isolation: Channel-to-channel and channel-to-backplane galvanic isolation
  • Hot Swap: Supported under redundant system configuration
  • Operating Temperature: -25°C ~ +70°C
  • Storage Temperature: -40°C ~ +85°C
  • Relative Humidity: 5%~95% RH, non-condensing
  • Status Indicator: Front LED indicators for module power, channel fault and communication status
  • Diagnostic: Detect open circuit, short circuit and out-of-range signal



Key Features

  1. 8 configurable analog channels, support both current and voltage signal types
  2. 16-bit high resolution, deliver precise measurement for process closed-loop control
  3. Multi-level galvanic isolation to suppress common-mode interference and protect backplane
  4. Built-in comprehensive channel diagnosis, quickly identify open/short circuit faults
  5. Hot-swap function, module replacement without full system shutdown
  6. G3 conformal coated PCB, stable performance in dusty and corrosive industrial environments
  7. Standard S800 rack installation, easy installation and on-site maintenance replacement
  8. Channel programmable filtering and scaling function, flexible matching different field sensors

XVC767AE102 3BHB007209R0101

ABB Same Series Related Models (≥6)

  1. XVC767AE102 3BHB007209R0102
  2. XVC768AE102
  3. XVC769AE102
  4. AI801 3BSE020508R1
  5. AO801 3BSE020510R1
  6. AI810 3BSE008516R1
  7. AO810 3BSE008522R1



Maintenance

  • Routine inspection: Check module LED status, baseplate connector and field signal wiring every 6–12 months
  • Clean module surface with dry compressed air; liquid solvent cleaning is strictly prohibited
  • ESD protection must be adopted during disassembly, anti-static wristband required
  • If signal deviation or channel alarm occurs, check field sensor, wiring integrity and channel configuration
  • Do not energize the module if PCB corrosion, burn marks or condensation are found
  • We support function testing, refurbishment and spare replacement service for this analog I/O module

XVC767AE102 3BHB007209R0101

Installation

  1. Hot-swap replacement can be performed following system safety procedure or cut off cabinet power supply.
  2. Wear anti-static wristband to prevent electrostatic damage to PCB components.
  3. Insert XVC767AE102 module into designated baseplate slot and lock the fastening latch.
  4. Connect field analog signal cables to module terminal blocks, ensure wiring tightness and shielding grounding.
  5. Configure channel signal type, range, filter and scaling parameters via engineering software.
  6. Check all connections and confirm no loose wiring inside cabinet.
  7. Restore power supply, download I/O configuration.
  8. Perform loop signal test, verify input & output accuracy and complete commissioning.
