Description

ABB TB826 3BSE061637R1 Single Mode Optical Media Converter, S800 I/O ModuleBus Fiber Transceiver, AC800M DCS Long Distance Optical Communication Spare Part



Product Application

TB826 is a long-range optical media converter dedicated for ABB S800 I/O ModuleBus. It converts signals between short-range HCS/plastic versatile link fiber and long-distance single-mode SC glass fiber, extending ModuleBus communication distance in star topology.

  • Power plant distributed I/O long-distance signal transmission
  • Petrochemical plant remote field I/O cabinet interconnection
  • Metallurgy rolling mill and furnace automation remote I/O communication
  • Cement plant large kiln and field instrument long-distance data collection
  • Water & wastewater treatment wide-range distributed control system
  • S800 I/O system upgrade and remote cabinet expansion projects
  • Legacy ABB AC800M DCS optical communication spare replacement

TB826 3BSE061637R1

Specifications

  • Part Number: TB826, 3BSE061637R1
  • Brand: ABB
  • Product Type: Single Mode Optical Media Converter
  • Compatible System: ABB S800 I/O, AC800M, HI Controller
  • Mounting: 35mm DIN rail mounting
  • Protection Class: IP20 (cabinet installation only)
  • Dimension: 136 × 85.6 × 58.5 mm
  • Weight: Approx. 0.27 kg
  • Power supply: 24VDC, typical consumption 96mA
  • Max communication distance: ModuleBus up to 5000m; S800 I/O HI up to 20000m
  • Fiber interface: Versatile link connector (HCS/plastic fiber) + SC single-mode glass fiber
  • Hot Swap: Not supported
  • Condition: Original new / refurbished spare available
  • Compliance: CE, EN 61010-1, UL 61010-1



Parameters

  • Communication Protocol: ModuleBus
  • Network Topology: Star configuration
  • Operation Mode: Slave
  • Redundancy: No module or line redundancy
  • Operating Temperature: 0°C ~ +55°C
  • Storage Temperature: -25°C ~ +70°C
  • Relative Humidity: 5%~95% RH, non-condensing
  • Pollution Degree: Degree 2
  • Status Indicator: Front panel LED for power and optical communication status
  • Function: Optical signal conversion between short-distance HCS fiber and long-distance single-mode fiber



Key Features

  1. Dedicated optical converter for S800 ModuleBus, realizes conversion between versatile link fiber and SC single-mode fiber
  2. Extend ModuleBus communication distance up to 5000 meters under star topology
  3. DIN rail snap-on mounting, easy installation inside field control cabinets
  4. Compact S800L mechanical design, seamless matching with S800 I/O system
  5. Front LED status indicator for fast optical link fault diagnosis
  6. Stable optical transmission, strong anti-interference for long-distance field I/O signal
  7. Ideal solution for wide-area industrial sites where I/O cabinets are far away from main controller room

TB826 3BSE061637R1

ABB Same Series Related Models (≥6)

  1. TB826 3BSE061637R1
  2. TB820 3BSE013208R1
  3. TB840 3BSE013209R1
  4. TB840A 3BSE013210R1
  5. TB850 3BSE013211R1
  6. TU807 3BSE039025R1
  7. TU841 3BSE020848R1



Maintenance

  • Routine inspection: Check LED status, fiber connector cleanliness and fiber cable integrity every 6–12 months
  • Clean optical fiber end face with professional fiber cleaning tools; do not use liquid solvent
  • ESD protection must be adopted during disassembly, anti-static wristband required
  • If optical link loss occurs, inspect fiber for breakage, dirt or bending damage
  • Do not plug/unplug optical fiber while the module is powered on
  • Do not energize the module if PCB corrosion, burn marks or condensation are found
  • We support function testing, refurbishment and spare replacement service for this optical media converter



Installation

  1. Cut off the 24VDC power supply before operation; hot swap is not supported.
  2. Wear anti-static wristband to prevent electrostatic damage to PCB and optical components.
  3. Clip TB826 module onto 35mm DIN rail inside cabinet and lock the mounting buckle.
  4. Connect HCS versatile link fiber to the module local port; connect SC single-mode field fiber to long-distance port.
  5. Ensure fiber connectors are clean and fully inserted, avoid excessive bending radius of optical cable.
  6. Restore 24VDC power supply.
  7. Check LED status to confirm optical link establishment.
  8. Verify ModuleBus data communication between controller and remote I/O, complete commissioning.
